·Forged Alloy Steel,Quenched & Tempered
·Ultimate Load is 4 times the Working Load Limit.
PART. NO. | CHAIN SIZE (mm) | DIMENSIONS(mm) | W.L.L. (tons.) | WEIGHT (kgs.) | ||
A | B | R | ||||
8SCL0080 | 8 | 23 | 41 | 61 | 1.6 | - |
8SCL0100 | 10 | 30 | 47 | 75 | 2.0 | 0.52 |
8SCL0130 | 13 | 34 | 53 | 89 | 3.2 | - |
