STAINLESS WOOD SCREWS

POPULAR SIZE OF CROSS RECESSED RAISED COUNTERSUNK HEAD SS304 SCREW DIN7995

	1.6	2	2.5	3	3.5	4	5	6
6	0.11	0.17	0.3
8	0.13	0.21	0.36	0.55
10	0.16	0.26	0.43	0.64
12	0.18	0.29	0.48	0.72	1.03	1.37
14		0.33	0.56	0.81	1.15	1.54
16		0.37	0.62	0.9	1.28	1.71
18			0.68	0.99	1.39	1.84	3.05
20			0.75	1.07	1.52	2	3.26
25			0.89	1.28	1.81	2.37	3.87
30				1.51	2.11	2.77	4.49	6.6
35					2.42	3.16	5.1	7.47
40					2.74	3.57	5.72	8.34
45						3.91	6.27	9.13
50						4.32	6.89	10
60						5.09	8.06	11.67
70						5.89	9.29	13.41
80							10.52	15.15
